7/11kW AC EV Charger is suitable for residential areas,private villas,commercial office buildings,parking lots and other places that can be charged slowly for a long time or temporary charging occasions.
Features
1. Innovativeness
Temper glass panel.Modern design
Business use with intelligent App control
Customizable
2. Intelligent Control
Wireless communication (wi-fi/Bluetooth),Ethernet/4G optional
OCPP communication protocol with CMS
Intelligent operation by card or cashless payment
3. Flexible Option
Universal Type 2 socket,Optional with Type1/Type2 charging cable
App operation or plug and play
Wall-mount or floor-stand installation
Technical Data
| Specification | Model | RWAC-WZ-7kW/220V | RWAC-WZ-11kW/220V |
| AC Nominal Input | Phases/Lines | 1 phase + netural+ PE | 3 phase + netural+ PE |
| Voltage | 220V±10% | 220V±10% | |
| Frequency | 50Hz | 50Hz | |
| AC Nominal Output | Voltage | 220V±10% | 220V±10% |
| Current | 32A | 16A | |
| Power | 7KW | 11KW | |
| Structure Design | Housing Material | Plastic PC940 | Plastic PC940 |
| Installation Method | Wall-mount/Floor-stand | Wall-mount/Floor-stand | |
| Wall-mount Bracket | Not necessary | Not necessary | |
| Charging Outlet | One charging gun(Type 2) | One charging gun(Type 2) | |
| Cable Length | 4 M | 4 M | |
| LED Indicator | Green/Yellow/Red color for different status | Green/Yellow/Red color for different status | |
| LCD Screen | No | No | |
| Emergency Stop Button | Yes | Yes | |
| RFID Function | Yes | Yes | |
| RFID Card | 2pcs Mifare card | 2pcs Mifare card | |
| Environmental Index | Operating Temperature | - 30~ + 60℃ | - 30~ + 60℃ |
| Working Humidity | 5%~95% without condensation | 5%~95% without condensation | |
| Working Altitude | ＜2000M | ＜2000M | |
| Protection Grade | IP54 | IP54 | |
| Application Site | Indoor/Outdoor | Indoor/Outdoor | |
| Cooling Method | Natural cooling | Natural cooling | |
| Security Protection | Multiple Protection | Over/Under voltage protection,Overload protection,Short circuit protection, Current leakage protection,Grounding protection,Surge protection, Over/Under temperature protection | |
| MTBF | 100,000 hours | 100,000 hours | |
| Safety Standard | IEC 61851-1:2017,IEC 62196-2:2016 | IEC 61851-1:2017,IEC 62196-2:2016 | |
| Warranty | 1 years | 1 years | |
| Package Information | Product Dimension | 233*150*69.5MM | 233*150*69.5MM |
| Package Dimension | 480*340*135MM | 480*340*135MM | |
| External Packing | Carton | Carton | |
